  • Russell
    replied
    From what I have read on the Internet you have to use a ford heater core ($83 from rock auto) and a flow restrictor I made one from an old brass plug.

    Leave a comment:


  • Russell
    replied
    I knew it was to good to be true. Looks like I will need the .007 dowel pins, going to check a 3 rd time.

    The engine cradle I made is nicer than hanging from a chain and better than in the car on jack stands but it's really close to the floor.

    Leave a comment:


  • Russell
    replied
    Originally posted by Beagle View Post
    wow, how many different transmissions will that take? Nice!
    "The QuickTime RM-6065 bellhousing connects a small block Ford engine to a Ford TKO 500-600, TR3550, or T5 Mustang"

    Leave a comment:


  • DanStokes
    replied
    Those are made to take about anything you can dream up to bolt behind it. That's the same one we put in the Volvo.

    Dan

    Leave a comment:


  • Beagle
    replied
    wow, how many different transmissions will that take? Nice!

    Leave a comment:


  • Russell
    replied
    By the time I got it all set up it was time to clean up for dinner. I need to check my work again but if I did it right it's within spec! Keeping fingers crossed!

    Leave a comment:


  • Russell
    replied
    I am preparing to do my 5.0 swap. Trying to buy parts get things set up, out of the way, and researching as much as I can before the big week next week.

    For those of you who have removed and installed the fuel lines on a Foxbody did you remove the struts first? It looks like the hardest part of removing the fuel lines will be getting them around the strut. Putting them back on the coupe looks like it will be worse because it already has weld in sub frames as well as the struts. Both cars currently donít have a motor or transmission installed.

    Leave a comment:


  • Huskinhano
    replied
    Russell, I'm not sure if I took pictures. A lot of the time working on this is when a have a couple free minutes and just get to it. This past Wednesday the pressure plate bolts came in the mail. I went down to the garage and put the clutch on while the wife was yelling for me to come up and eat dinner.

    I can run this flywheel on a 0, 28 or 50 oz motor and I can use any and pressure plate, 5.0 with dowels and M8 bolts or Borg & Beck 3 finger with 5/16" bolts. Pretty much the universal sbf flywheel.

    Leave a comment:


  • DanStokes
    replied
    I did my mount by drilling a hole in a 12" steel rule (NOT easy!) and bolting it on with one of the PP bolts. The other end fit nicely next to another PP bolt so I installed a fender washer on that bolt and just squished the rule in place. The mag base attached nicely to the rule - worked great and now I have a steel rule with a hole in it. I can mail it off to Wendell if helpful.

    Dan

    Leave a comment:


  • milner351
    replied
    remember what you're measuring - this one is easy to make your brain turn into scrambled eggs.... you're looking for two concentric circles.... (you don't have to center the dial indicator on the flywheel - that was my hang up originally)
    usually you have to remove a bolt or two or three bolts to find a nice flat spot to put the magnetic base on.
    having the small face "mini dial" indicator helps... I got one from Amazon - I'll let you know how it works (cheap mitutoyo knock off)

    most folks say to make a mark every 90 degrees - and record needle position (12, 3, 6, 9 o'clock positions for example)

    depending on where you start with your zero (and confirm it returns to zero when you've rotated 360 degrees so you know it hasn't moved during the process)

    the readings will tell you which way you need to move it.

    I bought both .007 and .014 dowels from Rob McK - we'll see if I need them - they were $29 a set -
    Russell - I'd be happy to send you the ones I don't use if you need them.

    That quicktime looks WAY smaller than my lakewood - that will fit in a much smaller tunnel than the AOD I butchered my 62 for.... hopefully I have plenty of room for the lakewood/TKO.

    Leave a comment:


  • RideTech_Ryan
    replied
    Originally posted by Beagle View Post
    yeah - stock cam too. Me too. BUUUUAAAHHH.



    to be transparent without giving it all away, the white car is carbureted, is not a dual plane, and has long tubes. It will pass inspection here because it's 29 years old and an antique. Stock long block and a dremel. Not stock cam. Let's be realistic though, that would be TWO projects out the door any time soon. The black car is not low budget, and I'm not pulling the heads back off to put E7's on. I've got 1100 in the white car as it sits, and I'll list everything I bought for it. It is low budget.

    ***** EXCEPT *****

    and I'm dead serious. If anyone has a B303 laying around for cheap, I would put it in the white car. If you know somebody with a B303 (All hail Beecam!), please get me in touch with them. I might get so churned up about a BEECAM!! I finish the black car and pull the white one in ASAP.

    (I'm back at the computer desk for as long as the project lasts, can't say a lot more than that. The guys I'm working with are extremely smart, so it's enjoyable enough.)

    THAT SOUNDS GREAT!

    Leave a comment:


  • DanStokes
    replied
    Nice oil pan!

    Dan

    Leave a comment:


  • Russell
    replied
    Can you take a picture of the clutch side? Did you find out if they just sell the other weight to go to 28 oz?

    That's one pretty motor! Mine will not be pretty.
    Last edited by Russell; July 1, 2016, 05:06 AM.

    Leave a comment:


  • Huskinhano
    replied
    I forgot to take a picture of the back side of my wheel. It's etched with it's SFI serial number. Here's a shameless plug of my P motor hopefully going in tomorrow. Stock exhaust manifolds are only temporary. I have to wait for $20 dollar bills to grow back on the money tree

    Last edited by Huskinhano; June 30, 2016, 07:59 PM.

    Leave a comment:


  • Russell
    replied
    Did not get any work done yesterday but I did unrap the goods. The FMS flywheel is a nice piece in stead of adding material for the counter balance they removed it from the other side. Every time I look at the bellhousing I have to remind my self how much I like walking.
