  • turning an outdated carb into a throttle body...



    the older carb is a barry grant 850 baerclaw and will most like be the thing used
    do I remove the boosters and guts.. or just leave them so it could be used as a carb again.. looks like the tps to use was listed in bam bams thread.. so a junkyard pull and I'll see what I can build/hack there..
    now the ic
    the 355 intake is just like this one, this is the dart for the 496 but same lay out..

    can that idle control stepper motor/selniod be mounted

    Click image for larger version

Name:	th_picsone-852.jpg
Views:	1
Size:	24.1 KB
ID:	878106here (see red arrow)
    or is that to close to the front runners

  • #2

    Re: turning an outdated carb into a throttle body...

    My thoughts on IAC is going to be "built in" to a 2" spacer with a channel up thru the carb body so it connects above the throttle plates. I plan on removing boosters, epoxying all holes and smoothing/polishing.
    Whiskey for my men ... and beer for their horses!

    Comment


    • #3

      Re: turning an outdated carb into a throttle body...

      My thoughts on IAC is going to be "built in" to a 2" spacer with a channel up thru the carb body so it connects above the throttle plates. I plan on removing boosters, epoxying all holes and smoothing/polishing.
      the iac is to let air in because the blades are closed.. having it above the blades, how that gonna work

      Comment


      • #4

        Re: turning an outdated carb into a throttle body...

        With it mounted in the carb spacer, that is where it will let the idle air into the engine ..... it needs to come from above the throttle blades as they will be closed at idle ....
        Whiskey for my men ... and beer for their horses!

        Comment


        • #5

          Re: turning an outdated carb into a throttle body...

          With it mounted in the carb spacer, that is where it will let the idle air into the engine ..... it needs to come from above the throttle blades as they will be closed at idle ....
          conected to the air cleaner housing?

          Comment


          • #6

            Re: turning an outdated carb into a throttle body...

            conected to the air cleaner housing?
            That'll work too ....
            Whiskey for my men ... and beer for their horses!
